8-Pixel WS2812B RGB LEDs Ring (Black PCB)

$8.99

  • Compatible with Adafruit NeoPixels LEDs
  • 26mm ID, 32mm OD, black PCB carrying 8 ultra-bright LEDs
  • Data In, Data Out, Power (5VDC recommended), and Ground pins available
  • 1×Female-Male Pair of JST-SM Wires included



SKU: LED-00038 Categories: , Tags: , ,

Description

This 8-pixel ring provides an excellent arrangement of WS2812B RGB smart LEDs for use in any electronics project. The circular pattern of individually controlled LEDs allows us to to create incredible lighting displays for data visualization, status indication, and many more tasks!

These rings are 32/26mm in diameter (outer/inner) and carry 8 ultra-bright WS2812B LEDs. We include a pair of the standard JST connector (1 male and 1 female) so that you can connect multiple rings in a row, or even other WS2812B products such as our flexible strips!

Each LED is positioned at an equal distance from the two adjacent LEDs.

Features:

  • 26mm ID, 32mm OD, black PCB carrying 8 ultra-bright WS2812B RGB LEDs
  • Hard, black PCB (1.6mm) with 4 pins for 5VDC, GND, Data In, and Data Out
  • 1×Female-Male Pair of JST-SM Wires included
  • Multiple rings can be interconnected using the included 3-pin JST connectors (soldering required)
  • Fully addressable LEDs allow for individual control of color and brightness
  • Compatible with Adafruit NeoPixels LEDs

Additional information

Item Weight

0.352 ounces

Package Dimensions

3.46 x 2.6 x 0.67 inches

ASIN

B07HLS587W

Item model number

LED-00038

Customer Reviews

.noUnderline a

Date First Available

January 12, 2017

Color Name

5050 RGB (Black PCB)

Material Type

Copper 2.0oz PCB

Size

WS2812B

Manufacturer

Visit the ACROBOTIC Store
